8-channel, full HD video streams over coaxial cables, simultaneously dual compressed H.264 streams for each channel, 240 fps
*HDD not included
- Overview
- Specifications
- Downloads
GTW2008 is a DTV gateway with the function of receiving signals sent from DTV cameras and then transmitting the DTV signals into IP signals which are ONVIF compatible. It can be easily integrated with existing NVRs in IP-based systems, espcially suitable for hybrid applications of DTV cameras and IP cameras.
Features
8-channel full HD 1080p DTV gateway
Transmitting DVB-T signals to Internet Protocal based ones
ONVIF compatible
Multiple compressed H.264 videos streams over a single coaxial cable
The original coaxial cables in a CCTV system can be reusable.
Dual, individually configurable video streams in H.264 for each channel, including one HD stream and one SD stream, both at 30 fps
Easy installation: no need to re-deploy or re-plan the structure
Greater transmission distance compared to CCTV DVRs an HD-SDI DVRs
| DRAM | 1GB DDR3 RAM |
| OS | Embedded Linux system |
| Input devices | USB mouse |
| HDD | HDD: 2 SATA ports (HDD not included) HDD capacity: max. 8TB eSATA: 1 eSATA port, max. HDD capacity 16TB |
Video | Video input: 8 channels (BNC) Video out: 1 HDMI, 1 VGA Video compression: H.264 Video streaming: dual streams for each channel, including one 1080p stream plus one VGA stream, both at 30 fps |
| Live view | Display splits: 1/4/8 Resolution: 1080p @ full screen; 1080p @ quad-split; VGA @ eight-split OSD information: camera title, date, time, video loss, motion detection, recording mode |
| Recording | Resolution: 1920x1080 @ full screen; VGA @ quad-split & eight-split Event: Alarm I/O triggered (optional), motion detection, video loss, HDD error Modes: manual/schedule/event Motion detection: supported |
| Playback & backup | Playback channels: 1/4/8 Search modes: timeline/event Playback control: Play/fast forward/slow forward at 6 different speed, frame by frame Backup mode: by converting backup videos into .avi formats and saving to a USB flash drive |
| Network | Interface: Gigabit Ethernet, RJ-45 Supported protocols: IPv4, ARP, TCP, UDP, ICMP, SMTP, HTTP, PPPoE, DDNS, UPnP Remote operation: Through PC software or APP |
| System Integration | Application programming interface: open API for software integration, SDK, ONVIF Intelligent video: face detection and recognition (optional), motion detection Alarm triggers: intelligent video, audio detection, digital input |
| Security | Authorization: max. 10 group accounts, with hiearchical authority Multiple users: supporting 3 users log-in on client side by side software or browser User access logs: system operation logs, users' log-in time, IP, and selected videos |
| Power | Power supply: DC12V 4A Power consumption: 7.94W (w/o HDD) |
| LED indicators | Camera status, WAN, HDD, power |
| USB interface | USB 2.0 x 2, USB 3.0 x 1 |
| Operating conditions | 0℃ ~45℃ (32℉~113℉) |
Dimensions (L x W x H) |
315 mm (12.4") x 220 mm (8.7") x 70 mm (2.8") |
| Weight | 2.2 kg (4.63 lb.) |
| Approvals | CE, FCC, RoHS |
