2MP, 1/3" Panasonic MN34229 CMOS sensor, supreme low light performance, video codec: H.265 / H264 / MJPEG, up to 30 fps in 2065 x 1553 resolution, triple streaming, PoE, CS-mount, Day & Night, ONVIF Profile S
*lens not included
- Overview
- Specifications
- Downloads
Features
1/3" Panasonic MN34229 CMOS sensor
2 Megapixels
Video codec: H.265, H.264, MJPEG
Triple individually configurable video streams
Up to 30 fps in 1920 x 1080 resolution (60 fps optional); 30fps in all other resolutions
HDR
Power over Ethernet (PoE)
CS-mount
Day & Night
Supporting ONVIF Profile S
| System on Chip (SoC) | Hi3516D |
| Image Sensor | 1/3" Panasonic MN34229 CMOS sensor |
| Lens (optional) | CS-mount IR-corrected |
| Shutter time | 1/10000 s to 1/8 s |
| Iris control | DC-iris |
| Day and Night | Automatically removable infrared-cut filter (optional) | Minimum Illumination | 0.005 Lux/F1.2 (color); 0.001 Lux/F1.2 (B/W) |
| HDR | 100dB |
| Video | Codec: H.265, H.264, Motion JPEG Resolutions: 1920 x 1080 to 320 x 180 Frame rate: up to 30 fps in 1920 x 1080 (60fps optional); up to 30 fps in all other resolutions Streaming: triple Rate control: VBR/CBR |
| Standards | ONVIF Profile S |
| Memory | 256 MB RAM, 16 MB flash |
| Network | Network Interface: 100 Mbps Ethernet Supported Protocols: IPv4, IPv6, HTTP, HTTPS, TCP/IP, FTP, SMTP, UPnP, IGMP, RTSP/RTP/RTCP, DHCP, NTP, PPPoE, DNS, DDNS, UDP, Bonjour, QoS |
| Audio | Audio Compression: AAC LC, G.711 PCM Audio Interface: microphone in, line out |
| System Integration | 1 alarm in, 1 alarm out |
| Power Source | DC 12V2A, Power over Ethernet (PoE) |
| Power Consumption | Typical 2.8W |
| Operation Condition | -10~60°C 10~90% RH (noncondensing) |
| Dimension (L x W x H) | 134mm*71mm*64mm |
| Weight | 375g |
